Description
The ART ProMix is a handy litttle mic mixer which allows three microphones to combine into one channel of output. Each mic channel on the ProMIX has both phantom power and low-frequency cut selectable via DIP switches plus a level control.
The balanced XLR line output can be connected to a mic input on a mixer. Headphones or a powered monitor can be connected to the Phone/Aux output for monitoring.
And if AC power is not available, the ProMIX runs on batteries as well.
Specifications
Maximum Gain +60dB
Input Impedance 600 ohms
Maximum Input Level -14dB
Maximum Output Level +14dB
Output Impedance 600 ohms
Total Harmonic Distortion 0.0002
Low Cut -3dB @ 100Hz
Clip Headroom 3dB
Output Phantom Power 12V DC
Power 12V DC (adapter) / 2x 9V (batteries)
Dimensions 5.625x3.75x1.75 inches (143mm x 92mm x 45mm)
Weight 1.5lb (680g)
