Description
ATW-R3250
3000 Series IEM Receiver (ATW-R3250)
Body-pack receiver for 3000 Series In-Ear Monitoring System (ATW-3255)
Features
- Durable wireless in-ear monitor system delivers high-quality sound and stable RF
- Ideal for use in houses of worship and performance venues
- Optimized internal digital signal processing provides exceptional stereo separation
- Wide UHF tuning bandwidth of 138 MHz for maximum versatility in an increasingly congested RF environment; available in frequency bands DF2 (470 – 608 MHz) and EG2 (580 - 714 MHz)
- Shares design elements with the 3000 Series UHF Wireless Systems for easy integration and compatibility
- Transmitter and receiver include OLED screens for optimal readout of key settings and alerts
- Offers network monitoring and control via Wireless Manager software
- A channel plan can be deployed to all network-connected transmitters via an RF scan from a single receiver, with no interference or third-order intermodulation
- Body-pack receiver operates continuously for up to 7 hours when powered by NiMH batteries and charged in the ATW-CHG3 or ATW-CHG3N charging station (sold separately)
- Stereo or mono operation with pan/personal mix controls
- Receiver is equipped with an efficient headphone amp to ensure clear, natural sound quality
- Custom audio settings include EQ, limiter, gain control and balance
- Receiver’s antenna diversity improves RF stability
- Included ATH-E40 professional in-ear monitor headphones feature propriety dual phase push-pull drivers for exceptional accuracy and clarity
- Transmitter is equipped with balanced XLR inputs and loop output, plus network port
Specifications
Receiver
- Receiving System Antenna diversity
- Audio output cable performs as a secondary antenna to ensure stable RF performance.
- Image Rejection >80 dB, typical
- RF Sensitivity 20 dBuV at 60 dBA S/N ratio (50 ohms termination)
- Headphone Output Jack 3.5 mm (1/8") TRS stereo mini-jack
- Headphone Output 40 mW (at 12 ohms)
- EQ Low: 80 Hz / 160 Hz / 320 Hz / ±9 dB in 3 dB step High: 6 kHz / 8 kHz / 10 kHz / ±9 dB in 3 dB step
- Limiter Selectable: -30dB to OFF (0 dB) in 6 dB steps
- Antenna Input SMA type, 50 ohms
- Operating Temperature Range -5℃ to +45℃ (23℉ to 113℉)
- Battery performance may be reduced at very low temperatures.
- Dimensions 64 mm (2.5")×23 mm (0.91")×82 mm (3.2") (W×D×H)
- Weight 102 g (3.6 oz) (without batteries)
- Accessories Included ATH-E40
- Battery Current/Life 4 to 6 hours (alkaline); 5 to 7 hours (Ni-MH, 1900 mAh); 11 to 13 hours (Lithium)
- Depending on battery type, usage, volume level and environmental conditions.
- Battery Type 3 V DC (two 1.5 V AA) (not included)
