Description
The BPCB4 is replacement cable for BPHS1-XF4 communications headset. It is The BPHS1 is a rugged broadcast stereo headset with closed-back circumaural (around-the-ear) ear cups and a professional boom-mounted microphone that can be worn on either side. It is designed for news and sports broadcasting, announcing and interviews. The headset’s microphone has a cardioid polar pattern tailored for pickup of speech with maximum voice intelligibility over a wide range of frequencies. It is more sensitive to sound originating directly in front of the element, making it useful in reducing pickup of unwanted sounds. The flexible gooseneck boom swivels for easy positioning on either the right or left side.
The dual earphones offer an extended frequency response of 20-20,000Hz and smooth, natural sound reproduction. At the heart of each earpiece, a 40 mm neodymium driver offers impressive power handling for high maximum sound pressure levels. Generously padded circumaural ear cups provide acoustic isolation and long-wearing comfort; the adjustable headband is also crafted and cushioned for listening comfort.
The headset includes a user-replaceable detachable 3.3 m (10.8') cable terminating in two output connectors, one each for the microphone and headphone: the microphone output is a 3-pin XLRM-type connector; the headphones’ output is a 3-conductor ¼" connector. Three windscreens are also included to protect against noise from breath and wind.
Features
- Microphone features polar pattern and frequency response tailored for natural, highly intelligible vocal reproduction
- Closed-back circumaural ear cups help seal out crowd noise and other background distractions
- Neodymium magnets in microphone and headphones for high output level & detailed sound reproduction
- Rugged design with user-replaceable cable and ear pads
- Cardioid pickup pattern of the dynamic microphone rejects off-axis sounds
- Boom-mounted microphone can be positioned on the left or right side
- Adjustable cushioned headband and lightweight design for long-wearing comfort
- Cable terminations:
- - 3-pin XLRM-type connector for microphone
- - ¼" 3-conductor for headphones
Specifications
Headphone Closed-back Dynamic
Microphone Cardioid Dynamic
Driver Diameter 40 mm (Headphone)
Magnet Neodymium (Headphone)
Voice Coil Copper-clad aluminum wire
Frequency Response 20-20,000 Hz (Headphone)
Frequency Response 40-20,000 Hz (Microphone)
Maximum Input Power 1,600 mW at 1 kHz
Sensitivity 100 dB (Headphone)
Sensitivity -57 dB (1.4 mV) re 1V at 1 Pa (Microphone)
Impedance 65 ohms (Headphone)
Impedance 560 ohms (Microphone)
Weight 264 g (9.3 oz)
Dimensions
- 82.0 mm (3.23") wide (earcup);
- 46.0 mm (1.81") wide (headband);
- 180.1 mm (7.09") long (boom), microphone extended;
- 24.0 mm (0.94") diameter (microphone)
Cable 3.3 m (10.8') long with 8-pin connector at headset end; 3-pin XLRM-type connector (microphone) and 6.3 mm (1/4") phone plug (headphone) outputs
Accessories Included 3 windscreens; spare connector screw2.0 m (6.5') long cable terminating in a 4-pin XLRF-type connector.
