Description
Like all other cards within the Audio ToolBox range, the AxC-AS16M/AxC-AS8M can be used in either the AVBx7 or AVBx3 platforms.
Using only one slot of the Audio ToolBox, the AxC-AS16M/AxC-AS8M provides 16 or 8 high-end Mic/Line input (both line and microphone level) with an incredible density for the AuviTran Audio ToolBox platform.
Key Features
- 16 or 8 microphone/line high density inputs card
- 16 or 8 balanced mic/line + high quality preamps
- Input sensibility +24dBu to -56dBu
- Analog gain range: 0 to +80dB (0.5dB step)
- E.I.N. < -126dBu
- Dynamic range > 115dB
- THD+N < -90 dB
- Phantom power +48V, individually controllable for each input
- 2 or 1 Sub-DB25 female connectors
- A linear 0.5 dB step digital attenuator/gain gives access to an input sensibility from -56dBu to +24dBu.
- +48V phantom power activation per channel, preamp value setting
Applications
Suitable for all professional applications that request large numbers of high-quality Mic/Line inputs with a reduced size:
- Featuring extensive capacity of high-performance microphones and line pre-amplification, high class AD converter chips and excellent circuit design
- These card sets a new quality, price, density ratio standards for professional audio applications.
- Attenuation/gain settings and vu-meter can be controlled and monitored individually per channel via network for a remote management from virtually anywhere using AVS-Monitor via IP, Dante, AVB or EtherSound Networks
- Individual gains and +48V phantom activation remote controls are manageable by Yamaha HA remote protocol enabling direct control and monitoring from Yamaha console/mixer
- Dedicated control page for monitoring and controlling all the card parameters (gain, phantom power on each channel, preamp values, vu-meter)
Audio ToolBox Platform Overview
Smart, expandable, and sustainable: meet AuviTran’s versatile and flexible platforms that brings convergence among network technologies and audio interfaces.
With two 19” rack chassis AVBx7 and AVBx3 both available in StageBox or Installation modes, plus 20 interface cards, build the configuration you need.
Specifications
General
- Size 200 mm x 100 mm x 40 mm –AuviTran Audio ToolBox platform cards format
- Power Supply +12V / +3.3V - Through AuviTran Audio ToolBox backplane
- Storage: Temp / Humidity -5°C to 70°C / 0% to 95% (non-condensing)
- Operating: Temp / Humidity 0°C to 50°C / 5% to 90% (non-condensing)
- Connectors 2x or 1x female DB25 connectors (Yamaha pinout)
- Optional: DB25 to Euro-Block plug available
Audio Inputs
- Number of inputs
- AxC-AS16M: 16 Mic/line inputs
- AxC-AS8M: 8 Mic/line inputs
Audio Inputs Specifications
- Sampling Frequency 44.1kHz, 48kHz, 88.2kHz or 96kHz
- ADC resolution 24 bits
- Input specification Balanced Mic/line
- Input maximum level +24 dBu
Audio Inputs MIC / Line Technical Specifications
- Analog Gain Range 0 to +80dB (0.5 dB step)
- Input sensibility +24dBu to -56dBu
- Input Impedance 2,7 kΩ (differential)
- E.I.N. @ (Rs=150Ω G=+80dB) -126dBu
- Dynamic Range > 115dB A-weighted (> 112dB un-weighted)
- THD+N (1KHz) < -90 dB
- Frequency response 20Hz – 20kHz +/- 0.2dB)
- Phantom Power +48 V (individually controllable for each channel)
Integration Environment
- Audio ToolBox platform AxC-AS16M/AxC-AS8M are cards for the AuviTran Audio ToolBox platform AVS-Monitor AVS-Monitor enables to remotely set, control, and monitor an IP, Dante, AVB network and provides enhanced control pages to manage the AxC-AS8M/AxC-AS16M card specific parameters.
- OS Supported Windows 10 for 32-64-bit versions
