Description
Blackmagic Mini Converter - SDI to Analog 4K
The Mini Converter SDI to Analog 4K from Blackmagic Design allows you to convert Single Link SD/HD/3G/6G-SDI to analog SD/HD component, composite, or S-Video. The down-converter lets you to connect professional SDI equipment which outputs resolutions up to Ultra HD 4K (3840 x 2160) and DCI 4K (4096 x 2160) with SD and HD analog video monitors and other equipment. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.
Using 6G-SDI technology, the Mini Converter supports resolutions up to UHD 4K at up to 30 fps and DCI 4K at 24 fps. The Mini Converter also supports Single Link SD, HD, and 3G-SDI signals and automatically detects the input video format and instantly changes. A redundant SDI input is provided as an optional back up, and an SDI loop-through output is available for sending the SDI signal to an additional device. Up to 16 channels of de-embedded SDI input audio can be outputted as AES/EBU digital audio or balanced analog audio output via 1/4" output jacks.
The Mini Converter's settings are controlled using the built-in DIP switches or via USB using the included software for Max OS X or Windows computers. The USB port also enables the firmware to be updated. For powering the device, a 12V power supply is included with international socket adapters.
Product Highlights
- Single Link SD/HD/3G/6G-SDI Input
- Component, Composite, & S-Video Output
- SD, HD, UHD 4K & DCI 4K Input Signals
- Automatic Input Signal Detection
- Redundant SDI Input & Looped SDI Output
- Analog & AES-EBU Digital Audio Outputs
- 24-bit, 48 kHz Audio
- Control via DIP Switches or Software
- USB 2.0 Port for Firmware Updates
- 12V Universal Power Supply Included
Additional Features
- 4:2:2 Sampling and color precision
- 24-bit, 48 kHz audio sampling
- Compliant with SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656, and ITU-R BT.601 standards
Specifications
Connections
- SDI Video Inputs
- 1 x SD, HD or 6G?SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
- SDI Video Outputs
- 1 x SDI Video Loop Output.
- Analog Video Outputs
- NTSC, PAL, S?Video and component SD/HD from 6G?SDI input.
- Analog Audio Outputs
- 2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
- Digital Audio Outputs
- 2 channels of professional balanced digital with standard 1/4 inch jack connections.
- SDI Redundant Input
- Automatically switches over if main SDI input is lost.
- Multi Rate Support
- Auto detection of SD, HD or 6G?SDI.
- Updates and Configuration
- USB
- Reclocking
- Yes
Standards
- SD Video Standards
- 525i59.94 NTSC, 625i50 PAL
- HD Video Standards
- 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
- 2K Video Standards
- 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
- Ultra HD Video Standards
- 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
- 4K Video Standards
- 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
- SDI Compliance
- SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M?B, SMPTE 425M, SMPTE ST?2081, ITU?R BT.656, ITU?R BT.601.
- SDI Video Rates
- SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K.
- SDI Video Sampling
- 4:2:2
- SDI Audio Sampling
- Television standard sample rate of 48 kHz and 24 bit.
- SDI Color Precision
- 4:2:2
- SDI Color Space
- YUV
- SDI Auto Switching
- Automatically detects SD, HD or 6G?SDI.
- Analog Format Support
- 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60
- Analog Color Space
- YUV
- Analog Color Precision
- 4:2:2
- Format Conversion
- HD down conversion
Software
- Software Control
- Mac™ and Windows™ software upgrade via USB.
- Internal Software Upgrade
- Via included updater application.
Operating Systems
- Mac 10.14 Mojave, Mac 10.15 Catalina or later.
- Windows 8.1 or Windows 10.
Settings Control
- Mini Switches or USB software.
Power Requirements
- Power Supply
- +12V universal power supply included with international socket adapters for all countries. Cable tie point.
- Power Consumption
- 8.04 Watts
- Operational Voltage Range
- 12 ? 31V DC
Physical Specifications
- Weight: 0.667 lbs
- Width: 4.84"
- Height: 0.9"
- Depth: 3.63"
Environmental Specifications
- Operating temperature
- 0° to 40° C (32° to 104° F)
- Storage temperature
- -20° to 45° C (-4° to 113° F)
- Relative Humidity
- 0% to 90% non?condensing
What's Included
- Mini Converter SDI to Analog 4K
- Software CD
- 12V universal power supply with international socket adapters
Warranty
- 3 Year Limited Manufacturer's Warranty.
