Description
The BM15A is a revolutionary nearfield monitor offering exceptionally high performance. Its full range extended bass response makes it the perfect nearfield monitor, particularly for commercial studios, project studios and post production facilities.
The BM15A is a relatively large 2-way active system comprising of a large 240mm (10") woofer, a special version of the Dynaudio ESOTEC soft dome tweeter and an electronic phase-aligned crossover, which feeds the build-in dual, high performance discrete MOSFET amplifiers.
The ESOTEC HF driver spells quality and headroom due to a dynamic headroom of 1000W, and the 240mm (10") bass driver is world-renowned for its 100mm (4") aluminium alloy voice coil, which outperforms most 300mm (12") drivers in terms of power output and sheer punch.
The electronics offer complex protection circuitry helping to prevent accidental damage to the drivers, while still providing maximum transient response.
The BM15A monitor is front ported for powerful and extended low frequency response, and the elegant matte cabinet has radius edges on the front baffle to reduce boundary effects and improve the overall sound quality.
Features
- Handcrafted aluminum drivers
- High-resolution 1.1" soft dome tweeter, pure aluminum voice coil
- 10" woofer, 4" pure aluminum voice coil
- 2 channel high grade 100/200Watt RMS amplifiers
- 124dB SPL peak power output
- Frequency response of 40Hz to 22kHz
- HF & LF analog trim filters
Specifications
Model BM15A
System 2-way Active Nearfield Monitor
Frequency Response (+/- 3 dB) 40 Hz - 22 kHz
Max SPL 1m, pair (IEC Long Term) 124 dB RMS
Max SPL 2m, 5.1 (IEC Long Term) 125,5 dB RMS
Input level for 85 dB SPL @ 1m (+4/-10) -18 dBu RMS / -34 dBu RMS
Input level for max peak SPL (+4/-10) +16 dBu peak / -1 dBu peak
Power consumption Idle: 40 W / Max: 300 W
Amplifier power Tweeter: 100 W / Woofer: 200 W
Resonance Frequency 39 Hz
Internal Cabinet Volume 27,5 liters
Bass Principle Bass reflex
Crossover Frequencies 1800 Hz
Crossover Slope 30 dB/oct
Tweeter Esotec 28 mm soft dome, rear chamber, Magnetic fluid. 4 mm die-cast alu front,
Woofer 240 mm/9”, One-piece molded polyprop cone, 100 mm/4” pure alu voice coil
Weight 18.6 kg / 41 lbs
Dimensions (WxHxL) 290 x 454 x 388 mm / 11.4” x 17.9” x 15.2”
