Description
The CYBER PAK™ is an all-in-one Dimmer/Power/MIDI Pack with multiple functions. This pack allows you to convert from a dimmer to a relay pack through the menu function.
Features
- (4) Channel Dimmer/Relay/MIDI Pack
- Individual DMX Address for each Channel
- Selectable Modes (Dimmer or Switch Pack)
- (16) Internal Chase Macros with Fade In/Out
- DMX Fail (loss of signal) Settings: HOLD/OFF/ON
- Power Failure Memory
DIMMER MODE:
- (4) Channel Dimmer (1, 2 or 4 Channel Option)
- Individual Channel Assignment & Output Limiter
RELAY MODE:
- (4) Channel Relay (1, 2 or 4 Channel Option)
- Individual Channel Assignment
CHASER MODE:
- (4) Channel Chase Controller
- 16 Internal Chase Programs
- Adjustable Fade Times
MIDI MODE:
- Receives MIDI Notes 001-128 Program
- MIDI In & MIDI Through Connections
Specifications
CONTROL / CONNECTIONS
- (2) 3-prong Edison Sockets per Channel (8 total)
- 5pin MIDI IN/OUT Ports
- 3pin XLR IN/OUT Ports
- (4) Button LED Display Control Panel
- Master Power Switch
SIZE / WEIGHT
- Length: 8.3” (212mm)
- Width: 10.4” (265mm)
- Vertical Height: 3.0” (75mm)
- Weight: 8.0 lbs. (3.6kg)
ELECTRICAL / THERMAL
- AC 120V 50/60Hz 20A Max
- 2,400W Max Power Consumption (600W per channel)
APPROVALS / RATINGS
- CE | cETLus
