Description
The DARTZ 360™ is a unique, compact, narrow beam luminaire featuring a new patent pending single source 50W RGB LED engine producing an impressive 3° aperture, amazing high output level, and smooth color-mixed effects that can be used in a variety of applications requiring no minimum safe project distance as with typical discharge lamp beam fixtures, fast and precise 16-bit continuous 360° pan and tilt rotation, 14 static-stamped metal gobos, 6-facet linear and 8-facet independent rotating prisms, 0-100% linear frost filter for wash effects, high speed electronic shutter and strobe, electronic dimming and variable dimming curve modes, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, DMX, RDM (Remote Device Management), Kling-Net, Art-NET, and sACN protocol support, Elation’s E-FLY™ internal wireless DMX transceiver, 5pin XLR, RJ45 etherCON, and powerCON TRUE1 in/out connections, full color 180° reversible menu display with multi-button control panel, battery backup for display power, and a multi-voltage universal auto switching power supply (100-240v).
FEATURES
- Compact Precise 360° Pan/Tilt Moving Beam Luminaire
- Patent Pending Single Source 50W RGB LED Engine
- No Minimum Safe Project Distance Like Discharge Fixtures
- 3° Sharp Aperture with Motorized Focus
- Fast and Precise 16-Bit Continuous 360° Pan/Tilt Rotation
- 14 Static-Stamped Metal Gobos
- 6 Linear and 8 Facet Independent Rotating Prisms
- 0-100% Linear Frost Filter for Wash Effects
- High Speed Electronic Shutter and Strobe
- Electronic Dimming and Variable Dimming Curve Modes
- DMX, RDM, Kling-Net, Art-NET, and sACN Protocol Support
- Elation’s E-FLY™ Internal Wireless DMX Transceiver
- Adjustable Refresh Rate Frequency and Gamma Brightness
- Flicker Free Operation for TV and FILM
Specifications
SOURCE
- Patent Pending 50W RGB LED Engine
- 50,000 Hour Average LED Life*
- *May vary depending on several factors including but not limited to:
- Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 29,562 LUX 2,746 FC @16.4’ (5m) (3° Full ON)
EFFECTS
- Motorized Focus
- 6 and 8 Facet Independent Rotating Prisms
- 0-100% Linear Frost Filter for Wash Effects
- High Speed Electronic Shutter and Strobe
- 16-Bit Variable Dimming Curve Modes
- Adjustable LED Refresh Rate and Gamma Brightness
COLOR
- RGB Smooth Color Mixing
GOBOS
- 14 Static-Stamped Metal Gobos
CONTROL / CONNECTIONS
- (3) DMX Channel Modes (19 / 22 / 25)
- 360° Continuous Pan and Tilt 8 / 16 Bit Movement
- Adjustable Refresh Rate (900-25,000 (Hz)
- Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
- 6 Button Menu Control Panel
- Full Color 180° Reversible LCD Menu Display
- DMX, RDM, Kling-net, Art-NET and sACN Protocol Support
- Elation E-FLY™ Internal Wireless DMX Transceiver
- 5pin DMX, RJ45 Ethernet In/Out
- powerCON TRUE1Power In/Out
SIZE / WEIGHT
- Length: 11.2” (284.15mm)
- Width: 7.7” (195.97mm)
- Vertical Height: 17.9” (454.7mm)
- Weight: 28.0 lbs. (12.7 kg)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 154W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP20
