Description
Studio Quality Effects at Your Feet
Premier recording studios worldwide use Eventide on hit after hit. ModFactor features Eventide's 29 best modulation effects without compromising quality OR flexibility.
Flexibility Built-In
Plug-and-play expression pedal control of wet/dry mix or any combination of parameters. Control program changes and vary parameters continuously via MIDI. Supports instrument or line level inputs and outputs. Plays well with others; adapts seamlessly with a wide variety of amps and other foot pedals.
Features
- Studio quality sound
- Software upgradeable via USB 2.0
- MIDI control via USB or MIDI in, out/thru
- Instant program change
- Real-time control with 10 knobs, MIDI, or expression pedal
- Tap tempo and MIDI clock sync/generate
- 100 factory presets, unlimited through MIDI
- True analog bypass
- Rugged cast metal construction
- Reliable metal footswitches for instant preset access
- Mono or stereo operation
- Guitar or line level inputs and outputs
Effects List
Chorus
- Liquid Chorus
- Shimmer Chorus
- Organic Chorus
- Classic Chorus
Phaser
- Negative Phaser
- Postive Phaser
- BiPhase Phaser
- Feedback Phaser
- PhaseX0 Phaser
Wah
- WahWah Q-Wah
- Voc-Wah Q-Wah
- Bass Wah
- Bass Vocal Wah
Flanger
- Positive Flanger
- Negative Flanger
- Jet Flanger
- Thru-o Flanger
ModFilter
- Lowpass ModFilter
- HiPass ModFilter
- BandPass ModFilter
Rotary
- Standard Rotary
- Giant Rotary
Tremolo
- Bias Tremolo
- Opto Tremolo
Vibrato
- Modern Vibrato
- Vintage Vibrato
- Retro Vibrato
Undulator
- Pitch Undulator
- Feedback Undulator
Ringmod
- Ring (DC) Ringmod
- String (AC) Ringmod
Specifications
Analog Input/Output
Input impedance 500K ohms
Output Impedance 470 ohms
Recommended Load Impedance 10K ohms or greater
Connectors
Input 1 (mono) ¼ inch mono phone jack
Input 2 ¼ inch mono phone jack
Output 1 (mono) ¼ inch mono phone jack
Output 2 ¼ inch mono phone jack
Expression Pedal ¼ inch mono phone jack
Aux Switch ¼ inch stereo phone jack
USB Type B Socket. Use 2.0 cables only.
MIDI In Five pin DIN (Female)
MIDI Out/Thru Five pin DIN (Female)
AC Adapter Jack Power Supply included (see below)
Physical
Power 9 VDC, 1200 mA, Tip hot (+)
Dimensions English 4.8" (H) x 7.5" (W) x 2.12" (D)
Metric 122 (H) x 190 (W) x 54 (D) mm
Weight 2.15 lbs, 1kG
