Description
Available from January 2021, the new MK2 Studio Monitors and BASS subwoofers bring a new level of precision, power and innovation to the world of sound engineering and producing. Run by a powerful DSP, all models feature full on phase linearization for better stereo imaging (HEDD Lineariser®) and CoP technology for using the speakers Closed or Ported. This makes them suitable for the entire range of professional audio applications, from producing music, to mixing and mastering, to broadcast- and video-editing.
TYPE 30 MK2
3-Way Powerhouse with on-board Lineariser® and CoP
- 3-Way-System with 2×7”+4” Woofer and High-Resolution HEDD AMT Tweeter
- Integrated Amplifiers with 3x300W for up to 125 dB SPL/pair
- Closed-or-Ported Functionality
- Integrated DSP with AD/DA: 96 kHz, 32 Bit
- HEDD Lineariser® Phase-Correction
- Adjustable LFE, Shelf and Desk Filters
Specifications
- Woofer (honeycomb diaphragm): 7’’ (2’’ voice coil)
- Midrange (honeycomb diaphragm): 4’’ (1.25’’ voice coil)
- Tweeter: HEDD AMT
- Crossover frequencies (48 db/oct): 250 / 3 200 Hz
- Input analog / digital (AES): 1x / 1x XLR
- Input impedance (balanced): 22 kΩ
- Input gain: ± 12 dB
- Input sensitivity (A/D modulation): -10 /-4 / 0 / +4 dB
- Output: AES “through”: XLR
- HEDD Lineariser®, disengageable, delay: 10ms
- Shelve filters high / low (.5 dB steps): ± 4 dB
- LF range (-3 dB): normal / extended / satellite: 32/ 26 / 80 Hz
- Desk filter: small / medium / large (180 Hz): -1/ -2/ -4 dB
- Frequency response (-3 dB): 32 - 40 000 Hz
- Maximum SPL (per pair): 125 dB
- Power amplifier 110 - 240 V: 3x 300W
- AD/DA Conversion: 96 kHz / 32 Bit
- Cabinet with satin lacquer finish: black or white
- Dimensions in mm (H x W x D): 280 x 530 x 338
- Weight: 21.5 kg
- Warranty: 2 years
