Description
LINEAR 9 110 XA
Optimised horns for perfect dispersion behaviour
The dispersion angle of each speaker’s horn is optimised for its intended use. The LINEAR 9 110 XA 10" speaker is equipped with an 80° x 60° wide dispersion horn for homogeneous near-field dispersion. It can be rigged either via the rigging points (steel cables or chains in combination with the AP-8 attachment point) or with the TB-28N tilt bracket.
Specifications
- Max. SPL @ 10% THD 126 dB half space (70 Hz – 12 kHz averaged)
- Max. SPL peak @ 10 % THD 129 dB half space
- Frequency response +/-3 dB 70 Hz – 19 kHz
- Frequency response -10 dB 65 Hz – 20 kHz
- Power amp output (RMS) 700 W
- Amp type Class D - biamped
- LF driver -
- Low-/mid speaker 1x 10", 2.5" voice coil
- HF driver 1", 1.4" voice coil
- Horn directivity 80° x 60° CD horn, rotatable
- Active crossover frequency 2 kHz FIR X-over with 60 dB/oct.
- Maximum input level +20 dBu
- Analog inputs 1x XLR combo balanced
- Analog thru 1x XLR balanced
- DSP Out 1x XLR balanced
- Network port Ethercon RJ45, 1x In, 1x Thru
- Filter presets Flat, Monitor, Low Cut, Remote
- Remote software DSP CONTROL (Windows, macOS)
- DSP functions Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
- Sample rate 96 kHz
- System latency Less than 2.6 ms
- Mains connector 1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V
- Power consumption 1 A / 100–240 V nominal according to EN 62368-1
- Clustering angle -
- Angles up (Monitor angle) 30°
- Pole mount DuoTilt 3°/7°
- Rigging points 5x M8 (AP-8)
- Carrying handles 2x SingleGrip
- Housing Birch multiplex
- Finish PU coating black
- Front grille 2 mm metal grille backed with black acoustic foam
- Dimensions (WxHxD) 36 x 54 x 31 cm 14-11/64 x 21-1/4 x 12-13/64"
- Weight 16.5 kg / 36.4 lbs
