Description
L SUB 1500 A – A LOW-END BOOST FOR THE LINEAR SERIES
LINEAR SUB 1500 A is – a 15” bass reflex subwoofer – a diminutive miracle of power. A powerful punch, precise playback and an impressive low end (all the way to 45 Hz) make this powered sub the perfect add-on to mid/high units from the LINEAR 3 family when particularly dynamic and crisp bass response is required. What’s more, LINEAR SUB 1500 A can also be used in combination with mid/high units from the LINEAR 5 family, or as a bass extension to the ELEMENTS EASY BASE, SMART BASE and LINE BASE systems.
Features
- Compact powered subwoofer
- 1200 watts
- 1 x 15″ speaker
- 131 dB Max SPL Peak @ 10% THD (halfspace)
- Ideal add-on to mid/high units from the LINEAR 3 family
- Can also be used in combination with LINEAR 5 mid/high units, or as a bass extension to the ELEMENTS EASY BASE, SMART BASE and LINE BASE systems
- Rugged wood enclosure
- Adjustable X-over frequency
- Integrated HK Audio MultiGrips
Specifications
- Max. SPL @ 10% THD 130 dB half space (40 Hz – X-Over averaged)
- Max. SPL peak @ 10 % THD 132 dB half space
- Frequency response +/-3 dB 49 Hz – X-Over
- Frequency response -10 dB 45 Hz – X-Over
- Power amp output (peak power) 1200 W
- Amp type Class D
- Active protection circuits Undervoltage-Protection, Thermoprotection, Short-Circuit-Protection, Overcurrent-Protection, Subsonic 24 dB/oct., Peak-Limiter
- LF driver 1x 15", 3" voice coil
- Active crossover frequency 100 Hz / 120 Hz variable with 24 dB/oct.
- Analog inputs 2x XLR combo balanced
- Analog outputs 2x XLR Thru balanced, 2x XLR Mid/High Out
- Input sensitivity +4 dBu @ Gain center-notched
- Mains connector 1x IEC socket with V-Lock cord retainer
- Power consuìption 3 A / 220-240 V (6 A / 100-120 V) nominal according to EN 60065
- Pole mount 1x M20
- Carrying handles 2x MultiGrip
- Housing 16 mm MDF
- Finish Black acrylic enamel
- Front grille 2 mm metal grille backed with black acoustic foam
- Dimensions (WxHxD) 48.5 x 48.5 x 59.5 cm 19-3/32 x 19-3/32 x 23-27/64"
- Weight 29.8 kg / 65.7 lbs
