Jogg
An Ultra-portable Stompbox Interface Designed for Musicians
Jogg's design is based on a "simple, compact, high performance" concept. Jogg is a USB interface with a 1 IN 2 OUT design. It boasts 44.1kHz and 48kHz sampling rates. Hotone's engineers designed a low-energy, high-performance digital platform for Jogg. This gives it uncompromising sound quality and low signal-to-noise ratio, using 24-bit analog-to-digital/digital-to-analog conversion (AD/DA Conversion) to maximize optimal sound quality. Jogg performs great in recording studios, and also with cell phones or tablets for mobile use.
Features
- Professional USB audio interface in a compact-size casing
- Advanced digital platform that delivers great sound quality and dynamic response
- 24-bit A/D/A conversion, 44.1kHz/48kHz sample rate
- Low audio latency
- Universal audio interface compatible with PC, Mac, iOS, and Android¹′²′³
- GAIN knob provides up to +12dB gain amount
- 1/4” Hi-Z instrument input
- 1/4” unbalanced stereo outputs
- Aux in and headphone output for expanded performance and monitoring
- XLR output takes a pristine signal direct to the mixer
- 9V DC power supply or USB powered
- Comes with a VStomp Amp software activation code
¹The mentioned manufacturers and product names are trademarks or registered trademarks of the respective owners, which are in no way associated or affiliated with Hotone Audio.
²Compatible with some Android devices. For better user experience, we recommend to use with iOS devices due to the diversity and audio performance of Android devices.
³No driver is needed when connecting to devices with USB Audio 2.0 support. For Windows OS, we recommend to use Hotone USB ASIO driver for best compatibility.
Specifications
- Input Impedance 1MΩ
- Output Impedance
- Unbalanced Output: 1K Ohms (Out L/R)
- XLR Output: 100 Ohms
- Headphones: 10 Ohms
- Power Requirement 9V DC center negative/USB bus power
- Current Consumption 200mA
- Dimensions 58mm (W) x 101mm (D) x 47mm (H)
- Weight 220g
