Description
CURV 500 I AMP
4-Channel Class D Installation Amplifier
- 4 channels with DSP control
- Purpose-designed for CURV 500® installations
- Low-profile 1U 19" rackmount construction
- Drives up to six CURV 500® satellites or one CURV 500® ISUB subwoofer per channel
- Single push encoder operation
- High-contrast OLED display
- Temperature controlled low-noise fan
- High-efficiency switch mode power supply
- Only 6.8 kg
Purpose-designed for CURV 500® installations the I AMP is a low-profile 4-channel Class D rackmount amplifier with high-efficiency switch mode power supply and 10 Hz – 22 kHz frequency response. Sporting DSP control with presets for various satellite and subwoofer configurations, delay and parametric EQ each channel delivers 240 watts RMS at 4 ohms with less than 0.01% THD.
Operating the I AMP is simple and intuitive with just a single push encoder and easily readable high-contrast OLED display. It features a soft start circuit, DC, overcurrent, thermal and short circuit protection plus a temperature controlled low- noise fan. Input is on balanced XLR and terminal block connectors. The I AMP is capable of driving up to six CURV 500® satellites or one CURV500ISUB subwoofer per channel providing terminal block and speakON-compatible output connectors.
Specifications
- Product type Power Amplifiers
- Type Installation Power Amplifiers
- Rated ouput power (1kHz @ 2,7 Ohms) 4 x 240 W
- Rated ouput power (1kHz @ 4 Ohms) 4 x 240 W
- Rated ouput power (1kHz @ 8 Ohms) 4 x 120 W
- Rated ouput power (1kHz @ 16 Ohms) 4 x 60 W
- Output circuitry Class D
- Frequency response 10 - 22000
- Total Harmonic Distortion (THD) < 0,01 %
- Protection circuits DC, over-current, Short circuit, soft start, thermal overload
- Controls Push encoder
- Indicators OLED Display
- Line inputs 4
- Line input connectors Terminal block, XLR
- Loudspeaker outputs 4
- Speaker output connections Speakon compatible, Terminal block
- Cooling temperature controlled low-noise fan, noiseless in idle mode
- Power supply Switching power supply
- Power consumption @ full load 1100W
- Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz, Switch mode power supply with power factor correction (PFC)
- Width 482 mm
- Height 44 mm
- Depth 420 mm
- Weight 6,8 kg
