Description
CURV 500 I SUB
10" Installation Subwoofer 200 W
- 10" bass reflex construction
- Purpose-designed for CURV 500® installations
- Shallow-depth enclosure
- 200 watts RMS power handling
- 47 – 150 Hz frequency response
- Available in black or white textured paint finish
- Includes low-profile wall and ceiling mounting bracket
Purpose-designed for CURV 500® installations the iSUB is a compact, shallow-depth bass reflex subwoofer loaded with a custom 10" transducer. It features a 47 – 150 Hz frequency response for tight, dynamic low frequency reproduction with punch and definition and 200 watts RMS power handling. Finished in black or white textured paint the elegant cabinet with steel grille provides terminal block and speakON-compatible input connectors plus eight M8 suspension points. The iSUB comes with a low- profile wall and ceiling mounting bracket and a set of rubber feet.
Specifications
- Product type PA subwoofer
- Type Passive
- Low/mid Woofer dimensions 10 "
- Load rating (RMS) 200 W
- Frequency response 47 - 150
- Impedance 3 Ohm(s)
- Loudspeaker inputs 2
- Speaker input connections Speakon compatible
- Speakers per amplifier channel (DSP44/45K) 2
- Cabinet material 15 mm MDF
- Cabinet surface texture paint
- Cabinet colour Black
- Cabinet construction Bass Reflex
- Width 610 mm
- Height 310 mm
- Depth 230 mm
- Weight 14,5 kg
