Description

Reckeen 3D Studio & LITE SDI 12G
Reckeen 3D Studio

The most all-rounded 3D broadcasting system in the industry

An advanced trackless 3D virtual studio workstation for broadcasters who value versatility, high quality and cost-effectiveness.
RECKEEN 3D Studio is an all-rounded product that will cover all of your broadcasting needs – starting from creating and designing your virtual scenography, through producing your 3D TV content, to mixing and broadcasting the material in real-time. Reckeen 3D Studio system is equipped with virtual cameras, which give you freedom to move around the whole virtual set at any angle without limitations, imitating a camera crane and cameraman’s natural movements; unlike in 2D solutions, where that movement is limited to only zoom in and out, and, left to right.

The system is compatible with other devices such as: switchers, production systems, any cameras, and more. Do you already work on a green screen and/or own other systems you are happy with? Great! - Reckeen can work not only as a stand-alone workstation, but also as a supplementary module to other equipment – expand your working environment with possibilities of 3D system!

Take your productions to a new level!

All necessary tools to produce 3D TV content

RECKEEN 3D Studio package contains all necessary tools and applications to produce 3D TV content, perfect for TV stations, Youtubers, Twitch, and other broadcasters, e-learning and education facilities, and for all creative people working with a green screen.

Built-in applications:

3D Studio Editor – edit your 3D studio, create 3D objects’ animations, adjust lighting, shadows, talent set-up, and more
3D Studio Wizard – create your own virtual studio from scratch
Still Editor – create captions, graphic boards, news tickers, and more.
SmartKey – PIP feature, with 4 independent chroma keys, that can generate 4 separate outputs with talents on different backgrounds
Reckeen Lite – 2D version of our system

Default content:

Over 50 ready-to-use sets and scenographies of different styles
Library of over 700 3D objects
Library of textures & materials – wood, metal, plastic, stone, fabrics, etc. in various colours – to customise any object, wall or floor inside a 3D studio.

System’s features:

4K resolution
6 NDI inputs and 1 output
Mixer
Switcher
Audio mixer
Recorder
Streamer
High-end chroma key – 4 independent channels
Supports 3D animations in .FBX format
High quality graphics – the system uses PBR techniques
Built-in audio panel

CONNECT UP TO 4 INDEPENDENT CAMERAS

RECKEEN 3DSPro system has 4 camera inputs, up to 4K resolution. It allows you to have up to two 4K or up to four Full HD camcorders connected to the RECKEEN’s workstation. Their signals are keyed independently in a high quality, thanks to four independent chroma key channels. Multiple inputs allow a user to make more complex productions with numerous talents filmed on different greenscreens, and also in different locations – if using an NDI connection.

ANIMATIONS

Animate any object within our virtual studio, or use imported rigged animations. Simple animations can be added to any 3D object in a virtual studio – application objects as well as imported ones. For more complex animations, you can import rigged animations from any external applications using FBX format. The animations can be easily triggered from within the production screen. For a realistic effect, reflections are added to any imported objects and animations.

STREAMING

Get even closer to your subscribers and followers with an easy, live streaming option! Stream to any social media and broadcasting platform directly from RECKEEN 3D Studio. Use ready-made streaming profiles to popular platforms such as YouTube, Facebook, Twitch and many more, or choose custom settings to stream to any other platform of your choice.

RECKEEN VKey-100 CONTROL PANEL

For optimised results during production, we recommend using RECKEEN VKey-100 control panel - a specially designed control panel for Reckeen 3D & Lite Virtual studios. It provides precise control over real-time video operations.

Reckeen LITE

ALL YOU NEED TO START YOUR OWN VIRTUAL STUDIO PRODUCTION

Create – Produce – Broadcast

This 2-dimensional, 4K, high quality system is the most all-rounded and affordable virtual studio workstation on the market. Easy-to-use software, automation features, editors – those are just a few reasons why RECKEEN LITE is perfect for everyone who wants to produce creative, interesting and professional-looking TV content.

The system is compatible with other devices such as: switchers, production systems, any cameras, and more.

Do you already work on a green screen and/or own other systems you are happy with? Great! - Reckeen can work not only as a stand-alone workstation, but also as a supplementary module to other equipment – expand your working environment with new possibilities!

WHAT IS RECKEEN LITE?

RECKEEN LITE a 2D virtual studio system, that includes high quality hardware combined with smart, efficient and easy-to-use software. The combination of quality and durability of the product with reasonable price point makes it perfect for novice broadcasters who strive for great results, innovative education facilities that want to incorporate technology into teaching and learning, for creating corporate materials and different kinds of presentations, and for all creative people who produce videos and TV content and aim for impressive outcome.

This complete workstation, together with pre-installed software, allows you to create, produce and broadcast material filmed on a green screen, and place it inside a virtual scenery.

Intuitive switcher, easy-to-use application, and many automation functions, make this product perfect for inexperienced users, and for those who work alone – this system makes it possible to create, produce and broadcast your content completely on your own.

All that and much more come with this budget-friendly system - RECKEEN Lite

Built-in applications and content:

30 ready-to-use sets and scenographies of different styles
VSM Lite Editor - create your own, unique scenography, and edit the existing ones
Still Editor – create captions, graphic boards, news tickers, and more.
SmartKey – PIP feature, with 4 independent chroma keys, that can generate 4 separate outputs with talents on different backgrounds

System’s features:

4K resolution
6 NDI inputs and 1 output
Mixer
Switcher
Audio mixer
Recorder
Streamer
High-end chroma key – 4 independent channels
High quality graphics – the system uses PBR techniques
Built-in audio panel

CONNECT UP TO 4 INDEPENDENT CAMERAS

RECKEEN Lite system has 4 camera inputs, up to 4K format. It allows you to have up to two 4K or up to four Full HD camcorders connected to the RECKEEN’s workstation. Their signals are keyed independently in a high quality, thanks to four independent chroma key channels. Multiple inputs allow a user to make more complex productions with numerous talents filmed on different greenscreens, and also in different locations – if using an NDI connection (NewTek’s innovative Network Device Interface technology enables compatible systems, devices, and applications to connect and communicate over IP to share video, audio, and data).

VIRTUAL SETS & VSM EDITOR

RECKEEN Lite, by default, comes with 30 professionally-prepared set designs in various styles and themes. Virtual sets contain decorations, furniture and virtual screens on which various media can be displayed.

Moreover, by using our free software - VSM Lite Editor, you can create your own, unique scenography, or edit the existing one provided with the system.

By using this intuitive application, everyone can create a unique design, tailored to individual needs and liking. The editor is provided within the RECKEEN Lite software, but it’s also a stand-alone software, available for free!

STILL EDITOR

Our Still Editor application allows you to create text panels and aesthetically impressive compositions in the form of graphic files with images and texts, such as news tickers. Texts can also be edited during broadcast, in real-time, without the need to go back to the application – this way you can place a text panel with a new content live on-air immediately.

STREAMING

Get even closer to your subscribers and followers with an easy, live streaming option!

Stream to any social media and broadcasting platform directly from RECKEEN 3D Studio.

Use ready-made streaming profiles to popular platforms such as YouTube, Facebook, Twitch and many more, or choose custom settings to stream to any other platform of your choice.

RECKEEN VKey-100 CONTROL PANEL

View AllClose

Specifications

Rackeen 3D Studio

SYSTEM SPECIFICATION

Video input

Reckeen SDI Virtual Studio System
SDI Video Input: 2 x SDI – 3G/HD/SD auto switching
HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k 30p
Reckeen HDMI Virtual Studio System
HDMI: 4 x HDMI 1.4 type A connector with support for 1080p60 two up to 4k 30p

Monitor output

2x DP output for monitor
2x HDMI output for monitor
1x DVI-D output for monitor

Audio input

Digital: embedded stereo on each SDI and HDMI
Analog:

2 x XLR two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
2 x Jack 6,3mm two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
Two types of microphones – dynamic and condenser with + 48V phantom

Video input

Reckeen SDI Virtual Studio System
SDI Video Output: 2 x SDI – 3G/HD
HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k 30p
Reckeen HDMI Virtual Studio System
HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k 30p

I/O Port

Tally Output: TL – DB9 – 4 channels
Reckeen External Keyboard port: RS – DB9 – RS 232
Reckeen External Audio port: LAN – Audio Link
Ethernet: Gigabit Ethernet LAN
PC/2: PC keyboard
USB:

2 x USB 3.0 (front panel)
4 x USB 3.0 (back panel)
1 x USB 3.1 (back panel)

Audio output

Digital: embedded stereo on each SDI and HDMI
Analog

2 x XLR two channels – professional balanced analogue audio stereo differential output (-10dBV, or 4dBu)
2 x Jack 6,3mm two channels – professional balanced analogue audio stereo differential output (-10dBV, or 4dBu)
1 x Jack 6,3mm – stereo Headphone output

Video formats

Reckeen SDI Virtual Studio System
Input

2 x HDMI v1.4, 2x SDI
2160p 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
PAL, NTSC

Output

2 x HDMI v1.4, 2x SDI
2160p 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
Reckeen HDMI Virtual Studio System

Input

4 x HDMI v1.4
2160p 30/25 on two HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
PAL, NTSC

Output

2 x HDMI v1.4
2160p 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50

Video standards

Reckeen SDI Virtual Studio System

SDI

SMPTE-425M 1080p (60/59.94/50/30/25)
SMPTE-292M

1080p (30/29.97/25)
1080i (60/59.94/50)

SMPTE-296M 720p (60/59.94/50)
SMPTE-259M
PAL, NTSC

HDMI Video standard – HDMI spec 1.4

Reckeen HDMI Virtual Studio System

HDMI Video standard – HDMI spec 1.4

Features

Downstream Key – x2
Media Format MPEG2, MPEG4 and H.264 containers: (avi, mpg, mpeg, mp4, mxf, mov)
Audio: WAV, MP3
Video Capture Format

H.264 (.mp4) MPEG-2 (.mpg)
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
H.264 up to 4k 30p

Still Picture – x2
Picture Format .png .jpg,.bmp
Still Text – x2
Still Editor included
Keyer – x4 Chroma Key/Luminance Key
Streaming

Facebook,
YouTube,
NicoNico
Ustream
NDI
and custom profiles

Software

Reckeen 3D package:

3D Production
3D Studio Editor
Wizard
MS 3D Paint
Still Editor

Reckeen Lite package:

Lite Production
VSM Lite Editor (also as a standalone version)
Still Editor

NDI®

NDI input:

4 input interchangeably as cam 1 to cam 4 with supported stream key or Reckeen chroma key
2 input interchangeably as media 1 and 2

NDI output: program out

SYSTEM FEATURES

TALLY

Tally output allows you to connect the LEDs signaling the active camera operation on the studio set.

NDI®

NewTek’s innovative Network Device Interface technology, is a royalty free standard enabling IP video workflows across Ethernet networks and represents the most prolific IP-based workflow in the industry.
© NDI® is a trademark of NewTek, Inc.

MICROSOFT PAINT 3D

You can create 3D objects you want to place in the virtual studio scenography in MS Paint 3D editor, that you get pre installed with RECKEEN 3D Studio.

STYLE: WHITE OR BLACK

You can launch the application in 2 different color schemes: light or dark.

SWITCHER / VIDEO MIXER

Production Switcher works like an actual switcher, it supports up to 12 media sources for the program and for the preview.

4 CAMERAS INPUT

Up to two 4K camcorders or up to four Full HD (4x HDMI or 2x HDMI and 2x SDI – depending on the version)

3G SDI

Up to 1080P Full HD 3G , 2x SDI

HDMI

Up to 2160P 30 or Full HD

2 x DSK

DSK allows you to place additional overlays on the screen, such as news tickers, station’s logo, or other graphic panels.

3D Studio Editor

3D Studio Editor allows you to modify and expand the ready-made virtual studio projects – including those you’ve created yourself in the Wizard.

3D Wizard

You can create your own set design in five steps.

TEXT EDITOR

Still editor is an additional module for creating text panels, complementary to the 3D & Lite production module.

Import from 3D

RECKEEN 3D Studio system supports .OBJ and .FBX formats, and it is in compliance with them.

PBR

PBR (Physical Based Rendering) – scenography, architecture or equipment elements visible on the screen reflect properties of their real-world counterparts.

REAL TIME PRESENTER SHADOWS

RECKEEN 3D Studio system’s engine renders talent / presenter’s shadows in real-time.

Shadows

For each item of equipment, RECKEEN 3D Studio system’s engine renders shadows in real-time.

Lights

You can find the following types of lights in RECKEEN 3D Studio: Ambient, Directional, Point and Spot.

Reflections

RECKEEN 3D Studio system renders real-time reflections from flat glossy surfaces. These reflections change in accordance with altering position of the virtual camera.

Chroma Key

RECKEEN 3D Studio & Lite offers 3 types of keys (Chroma key, Simple chroma key and Luma key), you can enable up to four keys at the same time!

Audio Control

RECKEEN 3D Studio & Lite comes with a sound mixer that allows you to set the sound levels for each of the available inputs.

Mic in

RECKEEN 3D Studio & Lite system supports two types of microphones – dynamic and condenser with + 48V phantom.

Audio link

External connector allowing you to connect additional audio input / output.

RECORD

Thanks to CAPTURE function you can record to a file on your hard drive.

Online shop

Under construction

Object library

The 3D Editor and Wizard Editor’s library contains a huge number of ready-made 3D studio components and equipment divided into different categories.

Multiview

In addition to the available previews of the prepared video material (PRV) and of the broadcast (PRG), Multiview enables you to configure and preview all the media from the media tray, which can be accessed on a separate monitor.

Single view

You can carry out production using a single monitor. It is recommended to distribute the Single view into 3 different monitors connected to the Reckeen system.

Global illum

Ambient – a type of light that fills an entire studio and illuminates all the objects evenly. Ambient light does not come from any particular direction and it falls on all the elements of 3D scene, helping you lighten or darken them.

Audio follow

this feature allows you to mute the sound of a chosen channel up until a video signal associated with the given sound source appears on the vision.

Transitions

Reckeen system supports basic transitions such as: Cut , Fade and FTB – Fade to Black.

VIRTUAL CAMERA

Reckeen system allows you to select one of four virtual cameras (virtual cameramen) and save up to 15 virtual camera shots for each camera.

3D SCENE

With advanced arranging features, Reckeen system allows you to create in real time fully realistic 3D scenes with elements that reflect their real-world counterparts’ behavior.

KEYBOARD

The Reckeen system can be fully operated with a PC keyboard and a mouse.

H.264

The application uses the H.264 codec to compress and encode video sequences.

4Kp30

4K technology is a new standard for video images.
In combination with excellent sound quality, picture 4K becomes a source of extremely realistic experience.
The Reckeen system allows you to work in 4K resolution.
This means operating the system’s up to two inputs and output in 2160p format, i.e. with a resolution of 3840×2160.
The chroma and luma key also work in 4K format.
You can choose from among 3 progressive scan operating modes, that is full frame frequency: p25, p29,97 and p30

Rackeen LITE

SYSTEM SPECIFICATION

Video input

Reckeen SDI Virtual Studio System

SDI Video Input: 2 x SDI – 3G/HD/SD auto switching
HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k* 30p

Reckeen HDMI Virtual Studio System

HDMI: 4 x HDMI 1.4 type A connector with support for 1080p60 two up to 4k* 30p

*Reckeen LITE Studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

Monitor output

2x DP output for monitor
2x HDMI output for monitor
1x DVI-D output for monitor

Audio input

Digital: embedded stereo on each SDI and HDMI
Analog:

2 x XLR two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
2 x Jack 6,3mm two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
Two types of microphones – dynamic and condenser with + 48V phantom

Video output

Reckeen SDI Virtual Studio System

SDI Video Output: 2 x SDI – 3G/HD
HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k* 30p

Reckeen HDMI Virtual Studio System

HDMI: 2 x HDMI 1.4 type A connector with support for 1080p60 one up to 4k* 30p

*Reckeen LITE Studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

I/O Port

Tally Output: TL – DB9 – 4 channels
Reckeen External Keyboard port: RS – DB9 – RS 232
Reckeen External Audio port: LAN – Audio Link
Ethernet: Gigabit Ethernet LAN
PC/2: PC keyboard
USB:

2 x USB 3.0 (front panel)
4 x USB 3.0 (back panel)
1 x USB 3.1 (back panel)

Audio output

Digital: embedded stereo on each SDI and HDMI
Analog

2 x XLR two channels – professional balanced analogue audio stereo differential output (-10dBV, or 4dBu)
2 x Jack 6,3mm two channels – professional balanced analogue audio stereo differential output (-10dBV, or 4dBu)
1 x Jack 6,3mm – stereo Headphone output

Video formats

Reckeen SDI Virtual Studio System

Input

2 x HDMI v1.4, 2x SDI
2160p* 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
PAL, NTSC

Output

2 x HDMI v1.4, 2x SDI
2160p* 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50

Reckeen HDMI Virtual Studio System

Input

4 x HDMI v1.4
2160p* 30/25 on two HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
PAL, NTSC

Output

2 x HDMI v1.4
2160p* 30/25 on one HDMI
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50

*Reckeen LITE Studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

Video standards

Reckeen SDI Virtual Studio System

SMPTE-425M 1080p (60/59.94/50/30/25)
SMPTE-292M

1080p (30/29.97/25)
1080i (60/59.94/50)

SMPTE-296M 720p (60/59.94/50)
SMPTE-259M
PAL, NTSC

HDMI Video standard – HDMI spec 1.4*

Reckeen HDMI Virtual Studio System

HDMI Video standard – HDMI spec 1.4*

*Reckeen LITE Studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

Software

Reckeen Lite package:

Lite Production
VSM Lite Editor (also as a standalone version)
Still Editor

NDI®

NDI input:

4 input interchangeably as cam 1 to cam 4 with supported stream key or Reckeen chroma key
2 input interchangeably as media 1 and 2

NDI output: program out

Features

Downstream Key – x2
Media Format MPEG2, MPEG4 and H.264 containers: (avi, mpg, mpeg, mp4, mxf, mov)
Audio: WAV, MP3
Video Capture Format

H.264 (.mp4) MPEG-2 (.mpg)
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
H.264 up to 4k* 30p

Still Picture – x2
Picture Format .png .jpg,.bmp
Still Text – x2
Still Editor included
Keyer – x4 Chroma Key/Luminance Key
Streaming

Facebook,
YouTube,
NicoNico
Ustream
NDI
and custom profiles

*Reckeen LITE Studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

SYSTEM FEATURES

TALLY

Tally output allows you to connect the LEDs signaling the active camera operation on the studio set.

NDI®

NewTek’s innovative Network Device Interface technology, is a royalty free standard enabling IP video workflows across Ethernet networks and represents the most prolific IP-based workflow in the industry.

STYLE: WHITE OR BLACK

You can launch the application in 2 different color schemes: light or dark.

3G SDI

Up to 1080P Full HD 3G , 2x SDI

SWITCHER / VIDEOMIXER

Production Switcher works like an actual switcher, it supports up to 12 media sources for the program and for the preview.

4 CAMERAS INPUT

Up to two 4K camcordes or up to four Full HD (4x HDMI or 2xHDMI and 2x SDI – depending on the version)

TEXT EDITOR

Still editor is an additional module for creating text panels, complementary to the 3D & Lite production module.

HDMI

Up to 2160P 30 or Full HD

2 x DSK

DSK allows you to place additional overlays on the screen, such as news tickers, station’s logo, or other graphic panels.

Chroma Key

RECKEEN 3D Studio & Lite offers 3 types of keys (Chroma key, Simple chroma key and Luma key), you can enable up to four keys at the same time!

Audio Control

RECKEEN 3D Studio & Lite comes with a sound mixer that allows you to set the sound levels for each of the available inputs.

Mic in

RECKEEN 3D Studio & Lite system supports two types of microphones – dynamic and condenser with + 48V phantom.

Audio link

External connector allowing you to connect additional audio input / output.

RECORD

Thanks to CAPTURE function you can record to a file on your hard drive.

Online shop

Under construction

Audio follow

this feature allows you to mute the sound of a chosen channel up until a video signal associated with the given sound source appears on the vision.

Multiview

In addition to the available previews of the prepared video material (PRV) and of the broadcast (PRG), Multiview enables you to configure and preview all the media from the media tray, which can be accessed on a separate monitor.

Single view

You can carry out production using a single monitor. It is recommended to distribute the Single view into 3 different monitors connected to the Reckeen system.

VIRTUAL CAMERA

Reckeen system allows you to select one of four virtual cameras (virtual cameramen) and save up to 15 virtual camera shots for each camera.

Transitions

Reckeen system supports basic transitions such as: Cut , Fade and FTB – Fade to Black.

KEYBOARD

The Reckeen system can be fully operated with a PC keyboard and a mouse.

H.264

The application uses the H.264 codec to compress and encode video sequences.

4Kp30

4K technology is a new standard for video images. In combination with excellent sound quality, picture 4K becomes a source of extremely realistic experience.The Reckeen system allows you to work in 4K resolution. This means operating the system’s up to two inputs and output in 2160p format, i.e. with a resolution of 3840×2160. The chroma and luma key also work in 4K format. You can choose from among 3 progressive scan operating modes, that is full frame frequency: p25, p29,97 and p30.
Reckeen LITE studio offers a Full HD resolution. By purchasing additional License Key, You can upgrade it to 3D Studio &LITE with 4K resolution.

LAYERS

With the Virtual Space Maker module it is possible to build a set with layers of image files and with layers representing Talent or screen areas, just like in the popular Photoshop.

View AllClose
