Description
RØDELink LAV is a professional-grade wearable microphone designed for use in a wide range of applications. The locking TRS connector is designed to pair perfectly with the RØDELink range of wireless microphones and most recorders with a 3.5mm locking microphone input.
The RØDELink LAV is perfect for anyone in need of a high-quality lavalier microphone with a rock-solid locking connector. It features a discreet 4.5mm omnidirectional microphone, which picks up sound from all directions, making it very forgiving when it comes to placement on talent.
A foam pop shield is supplied to minimise wind noise and vocal plosives (hard ‘b’, ‘t’ and ‘p’ sounds), as well as a durable mounting clip with in-built cable management for quick and easy rigging. It also features a hard-wearing 1.2m (4 ft) long Kevlar® reinforced cable, designed to withstand the rigours of any shoot.
Features
- Professional-grade lavalier mic with 3.5mm TRS locking connector
- High-quality omnidirectional condenser capsule
- Discreet 4.5mm miniature microphone
- Kevlar® reinforced cable
- Includes pop shield and durable mounting clip
Specifications
ACOUSTIC & ELECTRICAL SPECIFICATIONS
- Acoustic Principle Permanently Polarised Condenser
- Polar Pattern Omni-directional
- Output Impedance 3k Ω Typical
- Frequency Range 20Hz – 20kHz
- Maximum SPL 110 dB SPL (@ 1kHz, 1% THD into 1Ω load)
- Sensitivity -33.5db re 1 Volt/Pascal (21.00mV @ 94 dB SPL) +/- 2dB @ 1kHz
- Signal to noise Ratio 67 dB
- Equivalent Noise (A-weighted) 27 dB Typical
- Dynamic Range 83 dB Typical
MECHANICAL SPECIFICATIONS
- Dimensions 1200.00mmH x 4.50mmW x 4.50mmD
