Description
SX21 Tiny Two-Way Crossover
The SX21 is a 24dB/Octave two-way frequency crossover intended for sound reinforcement applications. It has a 1/4" input, Low and High frequency 1/4" Outputs, a single variable Crossover Frequency, separate Low and High Output level controls. It is powered by an included adapter.
Features
- 24 dB/Octave rolloff
- Mono 2-Way crossover
- 50Hz - 2.5kHz range
- 1/4" unbalanced Input and Outputs
- External power supply for low noise operation
Specifications
- Input Impedance: 10K Ohms
- Output Impedance: 1K Ohms
- Headroom: +10 dBV
- Power Requrements: 12 - 16 VDC 150 mA (Rolls part number PS27)
- Size: 4.25" x 3.625" x 1.5"
- Weight: 1 lb
