Description
Full HD image quality with 60fps frame rate
1920×1080/60p
See every presenter or conference participant more clearly. The 1/3-type CMOS image sensor captures smooth, crisply detailed, Full HD (1920 x 1080 60p) images with extremely low noise – even in low light conditions where other cameras struggle. High frame rate (60fps) operation ensures smoother, more fluid reproduction of moving subjects.
Powerful 20x/30x optical zoom
The 20x/30x optical zoom range is complemented by 12x digital zoom for frame-filling close-ups with every detail seen clearly. Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings.
Multi-format output video
SD/HD/3G-SDI, HDMI,CVBS
The KM/KS Model series can simultaneously output 1080/60p baseband video through 3G-SDI, HDMI stream.
Versatile connectivity options
VISCA, PELCO-D/P / RS-232C,422,485 and Support for RS-232C,422,485 communication allows easy connection with a wide range of peripheral products. The camera can also be controlled via VISCA protocols over a standard VISCA, PELCO-D/P.
Enhanced PTZ operation ±172°/ 220°
The powerful direct drive motor assures quiet, rapid movement to the target position over a wide pan/tilt angle range. PTZ synchronization ensures smoothly co-ordinated camera movements, while Pan/Tilt speed can be set to ‘Slow’ for smooth, professional looking transitions. A sequence of camera positions can be stored to memory and recalled as a preset ‘trace’.
Wide 57.4-degree viewing angle
See every meeting participant in a boardroom with a wide 65-degree horizontal viewing angle.
256 programmable presets
Store and instantly recall up to 256 camera positions via KM/KS Model PTZ Controller C series from specific controller.
Suitable for desktop or ceiling mounting
Image flip gives extra operating flexibility, allowing the camera to be sited on a boardroom table-top or ceiling mounted while maintaining proper image orientation.
Specifications
Camera
- Module: (12x) 1/19″ Exmor CMOS, (20x) 1/2.8″ Exmor R CMOS
- Valid Pixels: 1920[H]x1080[V] (Approximately 2.1 million pixels)
- Video output format: 1920x1080p60, 1920x1080i60, 1920x1080p30, 1280x720p60, 1280x720p30, 720x576i50(CVBS only), 1920x1080p59.94, 1920x1080i59.94, 1280x720p59.94, 1920x1080p50, 1920x1080i50, 1920x1080p25, 1280x720p50, 1280x720p25
- Video output: HD/3G-SDI, HDMI, DVI, CVBS
- Zoom Scale: Optical zoom: 12/20x, Digital zoom: 12x
- Lens: 12x Zoom Lens[f=4.7~56.4 mm F1.6~F3.5] / 20x Zoom Lens[f=4.7~94 mm F1.6~F4.7]
- Viewing Angle: 57.4°(W), 3.2°(T)
- Minimum Luminance:
- 0.2lx (Day)
- 0.1lx (Night)
- 0.005lx (DSS on)
Camera function
- Day&Night: AGC, TDN(ICR)
- Focus: Semiauto/ Auto/ Manual
- Image Flip: On/ Off
- Zoom Speed: 0~7
- Focus Near Limit: 30cm/ 1m/ 1.5m/ 2m/ 3m/ 5m/ 10m
- AF Sensitivity: Normal/ Low
- Defog Mode: Off/ Low/ Mid/ High
- High Sensitivity: Off/ On
- Noise Reduction: Off/ 1~5
- Aperture: 10, 0~15
- White Balance: Auto/ Indoor/ Outdoor/ One Push/ ATW/ Manual/ Outdoor Auto/ Sodium Auto/ Sodium/ Sodium Out Auto
- Program AE: Full Auto/ Bright/ Shutter Pri/ Iris Pri/ Manual
- WDR: Off/ On/ VE
- BLC: On/ Off
Pan / Tilt
- Moving Angle: Pan: -172?~ 172?(Non-Endless), Tilt: total 220?(-20?~ 0?~ 180?~ -160?)
- Moving Speed: Manual: 0.002?/sec ~180?/sec (Interlocked with the Zoom Scale), Preset: 300?/sec, Swing: 1?/sec ~ 180?/sec
- Preset setup: 256 Presets[VISCA], 255 Presets (Label setup, each display setup)[PELCO]
- Swing setup: 8 swings
- Pattern setup: 8 Patterns
- Group setup: 8 Groups (20 motions/Group)
- Other functions: Smart-Flip, Home Position Set, Auto Parking, Power Up Action etc.
General
- Cam ID: PELCO: 1~14, VISCA: 1~14 setting
- Communication: RS-422/485, RS-232C, IR Remote
- Protocol: PELCO-D/P, VISCA
- OSD: Menu, Position, etc.
- Power: DC 12V ± 10% (Max 1A)
- Dimension: 166 x 183 x 175 mm(W x D x H)
- Weight: Approximately 1.95kg
- Operating temperature: 0?C ~ 40?C(32?F~104?F)
