Description
MXCWNCS Networked Charging Station
The MXCWNCS Networked Charging Station charges 10 SB930 batteries in 4 hours. LED indicators display charge status, and a RJ-45 Ethernet connection enables battery levels to be monitored remotely. Includes IEC power cable and mounting hardware for wall or rack mounting.
The MXCWNCS Networked Charging Station is designed to blend into conference room aesthetics, keeping SB930 rechargeable batteries for the MXCW640 Wireless Conference Unit at the ready. It accommodates up to 10 SB930 rechargeable batteries, and LED indicators display the charge status for each battery. The MXCWNCS charges 10 batteries to 50% charge in 1.5 hours, and to 100% charge in 4 hours.
The RJ-45 Ethernet connection enables remote monitoring of battery charge status via the Microflex Complete Wireless graphical user interface. A storage mode partially discharges batteries for long-term storage or shipment.
The MXCWNCS includes an IEC power cable and hardware for mounting to a wall or in a standard 19-inch equipment rack
FEATURES
- Accommodates up to 10 SB930 rechargeable batteries
- 5-segment LEDs on the unit display charge status individually for every battery
- RJ-45 Ethernet connection enables remote monitoring of battery charge status in hours and minutes via Microflex Complete Wireless graphical user interface
- Charges 10 batteries to 50% charge in 1.5 hours, 100% charge in 4 hours
- Selectable storage mode partially discharges batteries for long-term storage or shipment
- Includes hardware for wall and rack mounting
- Includes IEC power cable
Specifications
NETWORK
- Interface Ethernet
- Link Speed 10/100Mbps
- Networking Addressing Capability DHCP or Manual IP address
- Cable Length 100m (max)
- Cable Type > Cat5e (shielded/unshielded)
- Connector Type 1 x RJ45
- Connector LED Status (Green) / Link Speed (Amber)
USER INTERFACE
- Display Type
- 5 LEDs per bay for charging indication
- 1 status LED
- 2 Ethernet LEDs
MECHANICAL
- Dimensions 72.4mm x 438.9mm x 193.5mm (2.9" x 17.3" x 7.6")
- Weight 2825 g
- Color Black
- Material Molded Plastic, Steel
- Mounting Type Tabletop, wall mount or rack (4U rackspace required)
ENVIRONMENTAL
- Operating/Discharging Temperature Range -20°C (-4°F) to 35°C (95°F) Discharging may occur when storage mode is enabled
- Charging Temperature Range 0°C (32°F) to 35°C (95°F)
- Storage Temperature Range -29°C (-20.2°F) to 60°C (140°F)
- Relative Humidity <95%
