Description
The hybrid tube/solid state DCL-200 dual channel compressor/limiter is high quality dual channel tube compressor and limiter.
The Summit Audio DCL-200 inclues stereo linking capabilities. Based on a hybrid design, the DCL-200 combines the most desirable sonic characteristics of vacuum tubes with the increased reliability of solid state devices. DCL-200 circuitry incorporates selected 12AX7A vacuum tubes with high reliability 990 op-amps in a transformerless signal path, giving you an incredibly clean, precise sound, with the overtones and warmth of tube technology.
Features
- Continuously variable attack and release times
- Adjustable threshold
- Variable slope (ratio)
- Output gain control
- Soft-knee transition characteristic
- Stereo link switch
- Dual true VU meters
- Side chain insert
- Bypass switch
- Hand crafted in the USA
It's everywhere!
A mainstay of both the live sound and studio environments, the DCL-200 has helped shape the sound of countless concerts and albums for decades, as well as holding down the fort in many of the best dance clubs around the world.
Dual hybrid design
The Summit Audio DCL-200 is a dual channel hybrid design compressor/limiter that incorporates hand selected vacuum tubes with high reliability 990 op-amps in a transformerless signal path, giving you an incredibly clean, precise sound with the subtle overtones and warmth of tube technology.
Studio and stage
The DCL-200 uses a soft-knee and program dependent transition characteristic that is extremely versatile and musical sounding, making it a go-to piece for tracking, mixing, and even mastering. Because of the program dependent nature of the DCL’s compressor, a higher slope will result in more compression but the circuit constantly adjusts itself to the incoming signal, making it easy to set and forget.
Internal power supply.
All Summit Audio products sport an internal high voltage power supply using an industry standard IEC connector.
Hand-crafted in the USA
Each piece of Summit gear is meticulously crafted by hand in our shop using only the best quality components and attention to detail. Quality components and engineering know-how are the critical element to the sound and longevity of audio gear.
3 year warranty.
All Summit gear comes with a 3 year limited warranty
Specifications
Size and Weight
- Height: 3.5 inches (8.89 cm)
- Width: 19 inches (48.26 cm)
- Depth: 10 inches (25.40 cm)
- Weight: 17 pounds (7.71 kg)
Power Configuration
- Internal AC Supply
- 40watts, 115 or 230 volts, 50 or 60 Hz (Rear Switchable)
- Fuse size .5 amp, slo-blo for 100/115 V
- Fuse size .25 amp, slo-blo at 230 V
Compressor
- Release Time: 45 mS to 10 S
- Slope: Adjustable from 1.1:1 to 7:1
Connections
- Inputs: +4 dB female XLR, Channel 1 & 2
- Outputs: +4 dB male XLR, Channel 1 & 2
- Side Chain: 1/4" jacks
Operating Measurements
- Frequency Response: 5 Hz to 70 kHz
- Noise: Less than –80 dBu at unity, 10 Hz to 80 kHz
- Distortion: Less than 0.05% at +4 dBu
- Output impedance is 75 W. The recommended output load is 600 W or more. Maximum output approaches +30 dBu.
