YSM6-2
Studio Monitors 75w, 6-inch powered studio monitors
The YSM6-2 features 1-inch black-silk diaphragm neodymium dome tweeters. These tweeters blend seamlessly into the specially designed low-diffraction waveguide which is integrated into the front baffle. The edges of the wave-guide perfectly couple the tweeter with the woofer, reducing sonic anomalies normally associated with driver/tweeter proximity. The fibre-reinforced composite cone woofers have also been designed to perform with sonic excellence, providing a wide dynamic range at all levels. Integrated DSP is utilized to deliver transparent signal processing and bi-amplification has been optimized for each driver. The woofer and tweeter have been perfectly time aligned to eliminate any phase irregularities usually associated with 2-way designs.
Features
- 6-inch low-frequency driver; 1-inch silk dome tweeter
- Balanced XLR and 1/4- inch TRS inputs
- Unbalanced RCA input
- High and Low Frequency Adjust Controls
- Built in HF and LF limiters
- Volume Control
Specifications
- System Type 2-Way
- Active or Passive Active
- Power Rating (Watts) 75
- Biamp Operation Only Yes
- Max SPL (dB) 105
- Frequency Response (Hz +/- 3db) 45Hz-22kHz
- Crossover Frequency (Hz) 2.1 kHz
- HF Driver(s) Neo Soft dome Ferro Fluid
- HF Power Rating (Watts) 25
- HF Protection Therm, Over voltage, Clip
- LF Driver(s) 6.5-inch composite
- LF Power Rating (Watts) 50
- LF Protection Therm, Over voltage, Clip
- HF Distortion 0.015
- LF Power Amplifier (Watts) Class D
- LF Distortion 0.01 %
- Cooling Scheme convection
- Power Cable Included
- Power Switch Back, with LED on Baffle
- Inputs 1 RCA
- Inputs - 1/4" Jacks 1
- Inputs - XLR 1
- Input Sensitivity (Vrms Sine) 1.2
- Level Controls 1
- LED Indicators power on front
- Enclosure Materials MDF
- Baffle Material MDF/ABS
- Covering / Finish Textured Vinyl
- Dimensions (DWH xbackW, inches) 10 x 9.5 x 15
- Dimensions (DWH xbackW, cm) 25.4 x 24.13 x 38.1
- Weight (lbs/kg) 15 / 6.8
